Single-Channel

RN6742N

1-Channel HD (2M) Decoder with MIPI (1x 2-Lane) Output

Features: QFN-24, 4mm x 4mm Package; 1080p (2M) Video Resolution; MIPI Output Interface; Built-in 1.8V LDO; -40°C to +85°C Operating Temperature Range; Designed for Industrial Applications

Description

The RN6742N is a single-channel HD (2M) video decoder designed for cost-sensitive industrial applications. Its unique small footprint makes it ideal for portable devices and designs where PCB space is at a premium. Combining affordability with proven reliability, the RN6742N is a practical choice for compact, high-performance video solutions in industrial environments.

Add Inquiry (0)

Applications

HD (2M) Video Decoding
Industrial and Consumer Video Capture System
Portable or Wearable Device

Package Information

Package	Dimensions	Leads	Package Code
QFN	4mm x 4mm	24	N

Key Parameters

Analog Input	Decoder Channel	Output Interface	Supply	Resolution	Current	Temp.
1	1	MIPI (1x 2-Lane)	1.2V 3.3V	1080p		-40°C to +85°C
